Place of Origin: | China |
---|---|
Brand Name: | Bichamp |
Certification: | IAF, SGS, UKAS |
Model Number: | FICUT® |
Minimum Order Quantity: | Negotiable |
Price: | Negotiable |
Packaging Details: | Wrapped film packaging+Non fumigation pallets 1100*1100, 1100*550, 800*800 |
Delivery Time: | Root 1-2 weeks, Coil 3-4 weeks |
Payment Terms: | L/C, T/T |
Supply Ability: | Over 20 million Meter Per year |
Series: | FICUT® | Blade Material: | M42 High Speed Steel |
---|---|---|---|
Application: | Solid Materials And Profiles | Advantage: | General Purpose Metal Cutting Blade |
Grade: | Industrial | Process Type: | Laser Welded |
Highlight: | M42 Vertical Bandsaw Blades,Vertical Bandsaw Blades Universal |
FICUT® M42 HSS Universal Band Saw Blade For General Purpose Metal Cutting
FICUT® M42 General Purpose Bi-Metal Bandsaw Blade
FICUT bi-metal bandsaw blade is used on portable bandsaw machines and hand-fed vertical bandsaw machines to cut carbon steels, tool steels, structural steels, pipes and tubes, die steels, stainless steels, alloy steels, profiles and solid applications.
The tooth material is made of M42 high speed steel edge, with positive rake angle and standard tooth set. This multi-purpose blade is designed for basic workshop operations, less frequent blade changes due to broad application spectrum, and longer blade-life than carbon steel blade.
• This band saw blade is available in variable pitch and constant pitch
Applications
• Carbon Steels • Stainless Steels
• Die Steels • Structural Steels
• Alloy Steels • Tool Steels
• Aluminium • Bronze/Brass
Tooth Form | Positive rake angle | Standard tooth | |||||||||
Width x Thickness | 1/1.5 | 1.4/2 | 2/3 | 3/4 | 4/6 | 5/8 | 6/10 | 8/12 | 10/14 | 14/18 | |
MM | Inches | α=7° | α=10° | α=10° | α=10° | α=10° | α=7° | α=7° | α=7° | α=7° | α=7° |
13x0.65 | 1/2x0.025 | VS-G | VS-G | VS-G | VS-W | ||||||
13x0.90 | 1/2x0.035 | VS-G£ | VS-G♦ | VS-G♦ | |||||||
19x0.90 | 3/4x0.035 | VP-G | VS-G | VS-G | VS-G | VS-G | VS-W♦ | ||||
27x0.90 | 1x0.035 | VP-G | VP-G | VP-G | VS-G | VS-G | VS-G | VS-G | |||
34x1.10 | 1-1/4x0.042 | VP-G | VP-G | VP-G | VS-G | VS-G | VS-G | ||||
41x1.30 | 1-1/2x0.050 | VP-G♦ | VP-G | VP-G | VP-G | VP-G | VS-G♦ | ||||
54x1.60 | 2x0.063 | VP-G♦ | VP-G | VP-G | VP-G♦ | ||||||
67x1.60 | 2-5/8x0.063 | VP-G♦ | VP-G | VP-G♦ | VP-G♦ |
♦—MOQ REQUIRED
Constant pitch
Tooth Form | Positive rake angle | Standard tooth | ||||
Width x Thickness | 3 | 4 | 6 | 14 | 18 | |
MM | Inches | α=10° | α=0° | α=0° | α=0° | α=0° |
13x0.65 | 1/2x0.025 | CS-S | CS-S | CS-S♦ | ||
13x0.90 | 1/2x0.035 | CP-S | CS-S♦ | |||
19x0.90 | 3/4x0.035 | CP-S | CS-S | |||
27x0.90 | 1x0.035 | CP-S♦ | CS-S | CS-S |
